Powder Feeder MPF700 Twin

Price Range : ₹ 4Lakh - 8Lakh
Brand Name
Shot Blaster
Product
Powder Feeder – MPF700 Twin
Feeder Capacity
30
Power
Up to 230V
Usage/Applications
Coating
Weight
32-40 KG
Grade
Manual, Automatic
Delivery Time
10-15 Days
Packaging
Wooden Box, Bubble Sheet Wrapping
Delivery Type
Land, Air, Ship
  • A feedback signal from scales and a number of sensors govern quantity control.
  •   The Powder Feeder can manage a wide range of powder feeding quantities, from extremely small to medium-sized volumes.
  •   As needed, the Powder Feeder feeds the machine with powder from a chamber.
  •   A carrying rail is used to feed in the powder through a small opening within the machine.

Powder Feeder MPF700 Twin

MPF 700T (Twin) Powder Feeder is specifically designed for thermal spray gun coatings. Its small size makes it a portable powder feeder, which can be carried to the site for job work. The unit is controlled to exact and repeatable feed rates. The powder tank (canister) is mounted on a hinged plate which allows users to simply remove excess powder and clean the interior. Separate powder feed and carrier gas controls do it easy to clear excess material throughout the spray system. A remote operation switch can be added to any gun.

Specification :

Number of Canisters 2
Canister Capacity 700 CC Each(1400 CC both)
Canister Dimensions (mm) 69mm (Inner Diameter) x 190mm (Height)
Cabinet Dimensions 30” L x 16” B x 23.5” H
Electricity 220V/ 1P/ 50-60 Hz Or 110V/ 1P/ 50-60 Hz
Weight (kg) 65.500 Kg (Approx.)

Features :

  • Its dual hoppers can be operated and controlled independently of each other, for processing flexibility to feed:
  • A single material using one or both hoppers
  • Two different materials simultaneously
  • Two different materials for a layered or bond coat/topcoat system
  • Designed for non-stop continuous operation of the same or different powders.
  • Feed rate can be simply varied from 1 RPM up to 29 RPM.
  • It has a digital display that ensures correct readings.
  • Remote or Local powder feed control selectable.
  • Sensor less vector control technique for accurate RPM control.
  • It is compatible with a wide range of thermal equipment such as Plasma, HVOF System and Combustion Powder Flame spray systems.
  • This unit is provided with a powder pressure gauge to regulate the pressure accurately.
  • Safety Valve is provided to release high canister pressure when required.

Powder Feeder MPF700 Twin Manufacturers in India

We are one of the best Powder Feeder MPF700 Twin manufacturers in India and we also provide Sand Blasting Machine, Portable Shot Blasting Machine, Grit blasting machine, thermal spray gun, metalizing gun, Shot Blasting Machine in India at a low price for sale. we are the best portfolio of thermal spray guns at the best price.
